Pulsar New Old Stock Reverse PSR5455G / 30-660 Dual V Band 0.72 0.72 Dual V band Standard 0.70 a/r 3" inlet

New Old Stock

EU warehouse clearance. These items are identical to current unit except for the compressor housings which do not have the PSR logo and for stainless steel v band housings these have the older style flange with no fire ring.

They are only available in the exact configurations listed , no other options are available in the sale.

Reverse rotation units are special order and not returnable in case of mistaken orders.

Please make sure its the correct unit.

Pulsar PSR5455G Reverse Rotation

• Recommended displacement 2.0 to 3.5 litres with power outputs up to 600hp possible.
• Dual Ceramic ball bearing system provides optimal turbo response & better durability by reducing play in the shaft.
• 9 Blade G-Aero Billet Compressor Wheel with Extended Tapered Tip Technology
• 9 Blade G-Aero Inconel 713c Turbine Wheel
• Anti-Surge ported-shroud compressor inlet, cover with integrated speed sensor port

SPEC

• Compressor Wheel: 54*67mm
• Turbine Wheel: 60*55mm
• Compressor Outlet: 2″ Hose
• Turbine Inlet:  2.5" Vband
• Turbine Outlet: 3″ V-Band
• Water Ports: 2-M14 X 1.5
• Oil Inlet: 7/16-24 UNF with a -4AN Restrictor pre-installed
• Oil Outlet: Std T3 Oil Drain Flange
• 2 options of turbine housing: Dual vband 0.72A/R; Dual vband 1.01A/R.
• 2 Adapters are available: Vband to T25 adapter; Vband to T3 adapter

Please note , T flange adapters are only supplied with housing options that state with adapter

It's strongly recommended to run water cooling to aid reliability.
