Pulsar Reverse Rotation PSR6255G / 30-900 T3 1.01 V Band (with adapter) No Housing
Regular price
£1,017.74
If you have any questions regarding this product please contact us straight away! We will be happy to assist you.
Seen this product cheaper? We have a price match guarantee!
**Reverse Rotation units are special order and therefore not returnable in the case of mistaken ordering. Please make sure you need a reverse unit before placing your order**
Pulsar PSR6255G
- Please note, T51R housing option requires an extra 7 days handling time
- Recommended displacement 2.0 to 3.5 litres with power outputs up to 900hp possible.
- Dual Ceramic ball bearing system provides optimal turbo response & better durability by reducing play in the shaft.
- 9 Blade G-Aero Billet Compressor Wheel with Extended Tapered Tip Technology
- 9 Blade G-Aero Inconel 713c Turbine Wheel
- T3 and T25 options come with adapter as per image.
- Anti-Surge ported-shroud compressor inlet, cover with integrated speed sensor port
SPEC
- Compressor Wheel: 62*76mm
- Turbine Wheel: 60*55mm
- Compressor Inlet: 4″ Hose
- Compressor Outlet: 2″ Hose
- Turbine Inlet: 2.5" V band, T3 or T25 (T3 and T25 are via an adapter)
- Turbine Outlet: 3″ V-Band
- Water Ports: 2-M14 X 1.5
- Oil Inlet: 7/16-24 UNF with a -4AN Restrictor pre-installed
- Oil Outlet: Std T3 Oil Drain Flange
It's strongly recommended to run water cooling to aid reliability.
